• Body, standard
• Bumpers, front and rear, painted Black, includes step-pad (Not available with (ZR7) Chrome Appearance package.)
• Grille, Black composite
• Headlamps, single rectangular halogen
• Daytime running lamps
• Mirrors, outside rearview, manual folding, Black (If the van is an extended model (*G**7**), or if the van has no rear windows, then the van will get a flat right side mirror. All other vans will have a convex right side mirror.)
• Glass, Solar-Ray light tinted, all windows
• License plate bracket, front
• Wipers, intermittent, front wet-arm with pulse washers
• Door, swing-out passenger side, 60/40 split

• Seats, driver and passenger high-back reclining buckets, adjustable, with head restraints and vinyl or cloth trim
• Seats, front vinyl reclining buckets, includes head restraints
• Floor covering, Black rubberized vinyl full length floor covering
• Key, single, 2-sided
• Oil life monitor
• Steering wheel, steel sleeve column, includes theft deterrent locking feature, Black
• Warning tones, headlamp on
• Tow/haul mode selector, IP mounted
• Theft-deterrent system, PASSLock
• Air conditioning, front manual
• Defogger, side window
• Sound system, ETR AM/FM stereo includes seek-and-scan and digital clock. Includes front door speakers (2)
• Console, Base, includes open storage bin
• Mirror, inside rearview, manual day/night
• Headliner, cloth, over driver and passenger
• Visors, padded, driver and passenger side with vinyl trim
• Assist handle, front passenger
• Lighting, 2 dome lamps, includes defeat switch and door handle-activated switches

• Brakes, 4-wheel antilock, 4-wheel disc
• Air bags, frontal, driver and right front passenger (Includes passenger side air bag deactivation switch on models with GVWR, 8600 lbs. (3901 kg) and above. Always use safety belts and proper child restraints, even with air bags. Children are safer when properly secured in a rear seat. See the Owner's Manual for more safety information.)
• Door beams, steel-side
• Daytime running lamps

ENGINE, VORTEC 4300 V6 MFI ($0)

• (195 HP [145.4 kW] @ 4600 RPM
• 260 LB.-FT. [351.0 N-m] @ 2800 RPM) (STD)

• 3.42 Axle Ratio
• Gray Painted w/Chrome Center Caps Wheels
• Custom Vinyl Seat Trim
• Deluxe Console
• Convenience Group
• Tilt & Cruise Convenience Group
• Power Door Locks w/Lockout Protection
• Electrochromic Inside Rear-View Mirror
• ETR AM/FM Stereo w/CD Player/Seek & Scan
• Solar-Ray Deep Tinted Glass
• Fixed Rear Door Glass
• Fixed Side Cargo Door Glass
• Swing-Out Rear Door Window Glass
• Swing-Out Rear & Side Door Window Glass
• Power Heated Black Outside Rear-View Mirrors
• Rear Body-Colored Halo Trim
• 145 Amp Alternator
• 800 CCA Heavy-Duty Battery
• Front Manual Air Conditioning
• Front License Plate Bracket
• Front beverage holders
• Variably intermittent wipers
• Power steering
• Passenger door bin
• Front wheel independent suspension
• Front anti-roll bar
• Dual front impact airbags
• Driver door bin
• AM/FM radio
• ABS brakes
• Voltmeter
• Air Conditioning
• 4-Wheel Disc Brakes

• Vehicle
• Rear Door Type: Dual Swing-out
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 600
• Maximum Alternator Capacity (amps): 105
• Maximum Alternator Watts: - TBD -
• Cooling System
• Total Cooling System Capacity (qts): 11.72
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 3600
• Gross Axle Wt Rating - Rear (lbs): 4000
• Curb Weight - Front (lbs): 2687
• Curb Weight - Rear (lbs): 2052.9
• Gross Vehicle Weight Rating Cap (lbs): 7200
• Gross Combined Wt Rating (lbs): 9500
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 4400
• Dead Weight Hitch - Max Tongue Wt. (lbs): 440
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 4400
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 440
• Suspension
• Suspension Type - Front: Independent Coil
• Suspension Type - Rear: Hypoid Multi-Leaf
• Spring Capacity - Front (lbs): 3600
• Spring Capacity - Rear (lbs): 4000
• Axle Type - Front: Independent
• Axle Type - Rear: Semi-Floating
• Axle Capacity - Front (lbs): 3600
• Axle Capacity - Rear (lbs): 4000
• Axle Ratio (:1) - Rear: 3.42
• Shock Absorber Diameter - Front (mm): - TBD -
• Shock Absorber Diameter - Rear (mm): - TBD -
• Stabilizer Bar Diameter - Front (in): 1.30
• Brakes
• Brake Type: Pwr
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12 x 1.14
• Rear Brake Rotor Diam x Thickness (in): 13 x 1.18
• Tires
• Front Tire Order Code: XEN
• Rear Tire Order Code: YEN
• Spare Tire Order Code: ZEN
• Front Tire Size: P235/75R16EL
• Rear Tire Size: P235/75R16EL
• Spare Tire Size: P235/75R16EL
• Front Tire Capacity (lbs): 1903
• Rear Tire Capacity (lbs): 2004
• Spare Tire Capacity (lbs): 1903
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Wheels
• Front Wheel Size (in): 16 x - TBD -
• Rear Wheel Size (in): 16 x - TBD -
• Spare Wheel Size (in): 16 x - TBD -
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr-Assisted
• Steering Ratio (:1), On Center: 17.2
• Steering Ratio (:1), At Lock: 17.2
• Turning Diameter - Curb to Curb (ft): 43.4
• Turning Diameter - Wall to Wall (ft): - TBD -
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 31
• Fuel Tank Location: LH Midship Inboard
• Doors
• Side Door Type: Swing-out
• Exterior Dimensions
• Wheelbase (in): 135
• Length, Overall w/rear bumper (in): 224.1
• Width, Max w/o mirrors (in): 79.4
• Height, Overall (in): 81.6
• Overhang, Front (in): - TBD -
• Overhang, Rear w/bumper (in): - TBD -
• Ground to Top of Load Floor (in): 27.7
• Ground Clearance, Front (in): 8.6
• Ground Clearance, Rear (in): 7.6
• Rear Door Opening Height (in): 49.4
• Rear Door Opening Width (in): 57.0
• Side Door Opening Height (in): 47.9
• Side Door Opening Width (in): 44.1
• Step Up Height - Front (in): 20.1
• Step Up Height - Side (in): 20.9
• Cargo Area Dimensions
• Cargo Area Length @ Floor to Console (in): 153.6
• Cargo Area Length @ Floor to Seat 1 (in): 127.8
• Cargo Area Width @ Beltline (in): - TBD -
• Cargo Box Width @ Wheelhousings (in): 52.7
• Cargo Box (Area) Height (in): 51.9
• Cargo Volume (ft³): 225.1
• Interior Dimensions
• Passenger Capacity: 2
• Front Head Room (in): 40.2
• Front Leg Room (in): 41.3
• Front Shoulder Room (in): 68.8
• Front Hip Room (in): 65.5
• Summary
• Vehicle Name: Chevrolet Express Cargo Van
• Body Style: 1500 Cargo Van 135" WB
• Body Code: ZW9
